Home > Travel Reduction Gear >

267 6796 227 6116 Travel Reducer CAT E329D Final Drive Without Motor

Product Categories
PNC EXCAVATOR PARTS CO., LIMITED
Contact Now

267 6796 227 6116 Travel Reducer CAT E329D Final Drive Without Motor

Brand Name : PNC

Model Number : CAT 325D, E325C

Place of Origin : China

MOQ : 1PC

Payment Terms : T/T, Western Union, Paypal

Delivery Time : 1-3 working days

Packaging Details : Wooden

Price : Negotiable

Nc No. : NC-RD008

Model : E329D, E325C

Part No. : 267-6796, 227-6116

Type : China aftermarket

Weight : 300-345kgs

Stock : lots of stock

Warranty : 6 months

Product name : E329D Travel Gearbox, E325D Reduction Gear Assy

Contact Now

227 6116 267 6796 Travel Reducer CAT E329D Final Drive Without Motor



CAT E325D Reduction Gear Assy 267-6796 Travel Reducer E329D Final Drive Without Motor



Description

CAT Excavator Spare Parts, E329D Travel Reduction Gear, E325D Gearbox

Application

CAT 329D Excavator

Model

E325D L, E325C, E329D, E329D L

Part No.

267-6796, 227-6116, 2676796, 2276116

Quality

China made, high quality

Weight

300-345 kgs

Packing

standard export wooden

MOQ

1PC

Lead time

About 1-3 working days

Payment

TT, Western union, Paypal, Paysend, RMB

Warranty

6 Months

Shipping Port

Huangpu Old Port, Shenzhen Yantian,Guangzhou



2676796 DRIVE GP-FINAL parts 320D, 320D FM, 320D FM RR, 323D LN, 323D SA, 325C, 325D, 325D L, 325D MH, 329D, 329D L, 329D LN

325C & 325C L Excavators BKW00001-UP (MACHINE) POWERED BY 3126B Engine
267-6877: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP31800297
296-6228: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP31800298
325D L & LN Excavator GPB00001-UP (MACHINE) POWERED BY C7 Engine
267-6877: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP43750345
333-2982: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP43750347
325D & 325D L Excavators AZP00001-UP (MACHINE) POWERED BY C7 Engine
267-6877: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP44170455
333-2982: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP44170458
325D L Hydraulic Excavator T2S00001-UP (MACHINE) POWERED BY C-7 Engine
267-6877: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP44420312
333-2982: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP44420314
325D Material Handler C4H00001-UP (MACHINE) POWERED BY C-7 Engine
296-6228: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP45040330
325D L Excavator MCL00001-UP (MACHINE) POWERED BY C-7 Engine
267-6877: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP45110335
333-2982: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP45110337

329D L & 329D LN Excavator BFC00001-UP (MACHINE) POWERED BY C7 Engine
267-6877: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP53790277
333-2982: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP53790279
329D L Excavator LGN00001-UP (MACHINE) POWERED BY C7 Engine
267-6877: FINAL DRIVE GP » SEBP53800184
329D L Excavator TPM00001-UP (MACHINE) POWERED BY C7 Engine
267-6877: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP53810274
333-2982: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP53810276
329D & 329D L Excavators MNB00001-UP (MACHINE) POWERED BY C7 Engine
267-6877: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP53820685
329D & 329D L Excavators BYS00001-UP (MACHINE) POWERED BY C7 Engine
267-6877: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP53830352
329D & 329D L Excavators DTZ00001-UP (MACHINE) POWERED BY C7 Engine
267-6877: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP54830354
333-2982: DRIVE GP-FINAL » (WITHOUT MOTOR) SEBP54830358



267 6796 227 6116 Travel Reducer CAT E329D Final Drive Without Motor



Parts on group E325D Travel Gearbox:



Pos. Part No Qty Parts name Comments
1. 3E-2338 [2] PLUG-PIPE
2. 267-6863 BJ [1] SHIM (0.75-MM THK)
  7Y-0752 BJ [1] SHIM (0.8-MM THK)
  267-6864 BJ [1] SHIM (0.85-MM THK)
  267-6865 BJ [1] SHIM (0.9-MM THK)
  267-6866 BJ [1] SHIM (0.95-MM THK)
  7Y-0753 BJ [1] SHIM (1-MM THK)
  267-6867 BJ [1] SHIM (1.2-MM THK)
  267-6868 BJ [1] SHIM (1.4-MM THK)
  7Y-0754 BJ [1] SHIM (1.6-MM THK)
  267-6869 BJ [1] SHIM (1.8-MM THK)
  267-6870 BJ [1] SHIM (2-MM THK)
  267-6871 BJ [1] SHIM (2.3-MM THK)
5. 094-0578 B [1] PLATE (8-MM THK)
  094-0579 B [1] PLATE (9-MM THK)
  094-0580 B [1] PLATE (10-MM THK)
8. 094-1528 [12] WASHER (53X84X1-MM THK)
9. 114-1540 J [4] PIN-DOWEL
10. 168-8452 J [2] BALL BEARING
11. 169-5589 [1] GEAR-SUN (24-TEETH)
12. 169-5590 [1] GEAR-SUN (24-TEETH)
13. 169-5592 [3] GEAR-PLANETARY (23-TEETH)
14. 169-5593 [3] GEAR-PLANETARY (23-TEETH)
15. 169-5601 [3] SHAFT-PLANETARY
16. 169-5602 [3] SHAFT-PLANETARY
17. 171-9387 [1] GEAR-RING (64-TEETH)
18. 191-2569 [3] BEARING AS (CAGED ROLLER)
19. 191-2570 [6] BEARING AS (CAGED ROLLER)
20. 191-2571 [1] CARRIER-PLANETARY
21. 191-2676 [1] GEAR-RING (72-TEETH)
22. 191-2683 [1] GEAR-SUN (20-TEETH)
23. 191-2684 [3] GEAR-PLANETARY (21-TEETH)
24. 191-2685 [3] BEARING AS
25. 191-2686 [1] CARRIER AS
  191-2687 [3] RACE-BEARING
26. 191-2689 [3] WASHER (34X70X1-MM THK)
27. 191-2690 [3] WASHER (42.3X70X1-MM THK)
28. 199-4503 [1] COVER
29. 207-1571 J [1] SEAL GP-DUO-CONE
  214-3570 [2] RING-TORIC
30. 267-6797 J [1] HOUSING-MOTOR
31. 267-6798 J [1] HOUSING
32. 267-6799 [1] CARRIER-PLANETARY
33. 267-6800 J [1] GEAR-COUPLING
43. 093-1731 [2] RING-RETAINING
44. 095-0891 [6] PIN-SPRING
45. 096-0433 [3] RING-RETAINING
46. 096-3216 M [2] SETSCREW-SOCKET (M12X1.75X12-MM)
47. 171-9298 [1] SEAL-O-RING
48. 179-8733 M [16] BOLT (M20X2.5X170-MM)
49. 7M-8485 [2] SEAL-O-RING
50. 7Y-0595 [3] SPACER (58X79.6X6-MM THK)
51. 7Y-5217 JM [16] BOLT-SOCKET HEAD (M20X2.5X70-MM)
52. 8T-3282 J [16] WASHER-HARD (22X35X3.5-MM THK)
53. 8T-4123 [16] WASHER (3.62X5.75X0.375-MM THK)
54. 9X-6032 M [12] BOLT-SOCKET HEAD (M10X1.5X30-MM)
55. 1U-8846 B   SEALANT-GASKET

      AVAILABLE REPAIR KIT(S):
  267-6818 J [1] KIT-FINAL DRIVE BEARING



267 6796 227 6116 Travel Reducer CAT E329D Final Drive Without Motor


Payment &Packing &Shipping:



A). TT transfer, Western Union, Paypal, Moneygram are acceptable.



B). Light goods inner box is neutral white with an strong outer box.Heavy goods wooden with standard packing.If you have legally registered patent,

we can pack the goods in your branded boxes after getting your authorization letters.



C). Delivery time: depends on items you buy, most electric parts can shiped within 1-3 working days.



D). DHL /Fedex /UPS /TNT/ARMEX/SF Express ,etc. normal express shipping way for small cargo.Russia,Kazakhstan, Ukraine Russia Special Line,

Bangladesh,Myanmar,Vietnam ect, competitive shipping way no need you do customs clearance.Door to Door.



267 6796 227 6116 Travel Reducer CAT E329D Final Drive Without Motor



Warranty Statement:



1. Warranty Type: We will replace the product which have quality problem.


2. Warranty Period: Supply 3 months warranty for the products from the date of arrival. Customer should check the items according to the order list after arrival.

Contact with us and offer the data, photos of the problem items



3. You need to pay for the replacement charge for following condition:

* Wrong Order from customer.
* Natural Disasters cause the damage.
* Error installation, improper use.
* The machine and reducer work over time and over load.
* Lost by any condition.
* Human element destroyed.
* Corrode with rust during stock and running.
* Warranty Expired.
